5495 Self-locking mortise lock with emergency exit function

Skip slider
  • Self-locking mortise lock with emergency exit function
  • Self-locking mortise lock with emergency exit function
Self-locking mortise lock with emergency exit function
  • Self-locking mortise lock with emergency exit function
  • Self-locking mortise lock with emergency exit function

Item no. 5495

Find a retailer now
Assignment category4.5.1
Backset55, 60, 65, 80 mm
Backset (1)30 mm
Certified according to EN 179Yes, with 9 mm follower square pin
CylinderProfile cylinder
Deadbolt throw20 mm
Deadbolt turn1-turn
Deadbolt typeStandard
Direction must be statedYes
Distance72 mm
Dust and shavings protection thanks steel sleevesYes
Fire protection tested according to EN 1634-1 and 4102-18Optional, with 9 mm follower square pin
Flat forend (standard design)20 x 3 mm, 24 x 3 mm
Follower8, 9 mm
Follower turning angle26°
For rebated and non-rebated doorsYes
Forend length235 mm
Forend materialStainless steel
Latch bolt exclusion12 mm
Latch bolt typeStandard
Lock case depth15,5 mm
Lock case height165 mm
Lock case materialSteel galvanised
Lock case widthsBackset + 30 mm
Notice FollowerClamping-follower with slide bearing
Requirement according to DIN 18251-1Class 3
Suitable striking plates9368, 9171
FunctionLocks automatically as soon as the door closes, but only after the latch bolt is precisely positioned in the strike plate (patented mechanism). Inside handle: Handle operation causes latch bolt and deadbolt to retract. Outside door knob: Key operation causes latch bolt and deadbolt to retract (latch lever function). Please note that this lock cannot be used in conjunction with eletric door openers! Maximum gap between door and frame: 8mm
Series5495
