3603 External cylinder for rim locks

Skip slider
  • External cylinder for rim locks
  • External cylinder for rim locks
External cylinder for rim locks
  • External cylinder for rim locks
  • External cylinder for rim locks
Find a retailer now
Assignment Category3.2.4
Diameter24 mm
Fixing screw2 x M5
Key InsertingHorizontal
Key with custom logoOptional
Number of pin tumblers6
Picking resistanceYes
With Connection pinYes
With fixing plateYes
With RoseYes
Material / ColoringBrass nickel-plated matt
Material / Coloring specialBrass chrome polished, chrome matt, polished, matt brushed
Compatible SystemsStandard profile reversible key system, 3VS, 2VS, S3, S5

4

Results found

Show per page

DescriptionLanguageFile sizeFile type
EPD de 698.13 KBpdfDownload
EPD en 590.25 KBpdfDownload
3603-produktfoto.png76.36 KBpngDownload
3603-techzeichnung.png43.66 KBpngDownload

Compatible systems

Skip product slider
  • Reversible key system W3600 Reversible key system W3600

    Standard profile reversible key system Reversible key system W3600

  • Reversible key system 3VS Keying systems Reversible key system 3VS Keying systems

    3VS Reversible key system 3VS Keying systems

  • Reversible key system 2VS Keying systems Reversible key system 2VS Keying systems

    2VS Reversible key system 2VS Keying systems

  • Reversible customer keyway Carat S3 Reversible customer keyway Carat S3

    S3 Reversible customer keyway Carat S3

  • Reversible customer keyway Carat S5 Reversible customer keyway Carat S5

    S5 Reversible customer keyway Carat S5
