1463 Double cylinder with emergency exit function

Skip slider
  • Double cylinder with emergency exit function
  • Double cylinder with emergency exit function
Double cylinder with emergency exit function
  • Double cylinder with emergency exit function
  • Double cylinder with emergency exit function
Find a retailer now
Assignment Category3.2.1
DIN tested attack resistance class A or DOptional
Drilling protection (ABH)Optional
Drilling protection (ABH) typeI, III, V
Emergency functionYes
FunctionCylinder will operate even if a key has been left in the cylinder on the opposite side
Hardwearing designOptional
Key InsertingVertical
Key with custom logoOptional
Length A and B can be combined arbitrarilyYes
Maximum length A90 mm
Maximum length B90 mm
Minimum length A30 mm
Minimum length B30 mm
Number of pin tumblers6
Picking resistanceYes
Seawater-resistant designOptional
SKG certifiedOptional SKG** or SKG***
Special lengths on requestYes
VdS certifiedOptional VdS***
Material / ColoringBrass nickel-plated matt
Material / Coloring specialBrass chrome polished, chrome matt, polished, matt brushed, black
Compatible SystemsStandard profile conventional, SI6, S1, S4

14

Results found

Show per page

DescriptionLanguageFile sizeFile type
DIN Zertifikat de 228.46 KBpdfDownload
DIN Certificate en 228.46 KBpdfDownload
Zertifikat SKG 2 Sterne de 274.62 KBpdfDownload
Certificate SKG 2 Stars en 274.62 KBpdfDownload
Certificate SKG 2 Stars en 274.73 KBpdfDownload
Zertifikat SKG 2 Sterne de 274.73 KBpdfDownload
Certificate SKG 3 Stars en 271.74 KBpdfDownload
Zertifikat SKG 3 Sterne de 271.74 KBpdfDownload
EPD de 698.13 KBpdfDownload
Certificate VdS 3 Stars en 574.26 KBpdfDownload
Zertifikat VdS 3 Sterne de 574.26 KBpdfDownload
EPD en 590.25 KBpdfDownload
1463-produktfoto.png64.26 KBpngDownload
1463-techzeichnung.png24.79 KBpngDownload

Compatible systems

Skip product slider
  • Standard cylinder Standard cylinder

    Standard profile conventional Standard cylinder

  • Verical system SI6 Keying systems Verical system SI6 Keying systems

    SI6 Verical system SI6 Keying systems

  • Verical customer keyway Carat S1 Verical customer keyway Carat S1

    S1 Verical customer keyway Carat S1

  • Verical customer keyway Carat S4 Verical customer keyway Carat S4

    S4 Verical customer keyway Carat S4
