0503 External cylinder for rim locks
Skip slider External cylinder for rim locks
End of slider
| Assignment Category | 3.2.4 |
| Diameter | 24 mm |
| Fixing screw | 2 x M5 |
| Key Inserting | Horizontal |
| Key with custom logo | Optional |
| Number of pin tumblers | 6 |
| Picking resistance | Yes |
| With Connection pin | Yes |
| With fixing plate | Yes |
| With Rose | Yes |
| Material / Coloring | Brass nickel-plated matt |
| Material / Coloring special | Brass chrome polished, chrome matt, polished, matt brushed |
| Compatible Systems | Standard profile conventional, SI6, S1, S4 |
