0453 Heavy-duty mortise lock for tubular frame doors
Item no. 0453
| Assignment category | 4.1.1.8 |
| Backset | 19, 24, 29, 34, 39, 44 mm
|
| Backset (1) | 15 mm
|
| Cylinder | Profile cylinder
|
| Deadbolt extended | 5 mm
|
| Deadbolt throw | 15 mm
|
| Deadbolt turn | 1-turn
|
| Deadbolt type | Standard
|
| DIN Direction | DL / DR
|
| Direction must be stated | No
|
| Distance | 92 mm
|
| Flat forend (standard design) | 24 x 3 mm
|
| Follower | 8 mm
|
| Forend length | 257 mm
|
| Forend material | Stainless steel / Iron galvanised
|
| Latch bolt exclusion | 11 mm
|
| Latch bolt extended (optional) | 5 mm
|
| Latch bolt type | Standard
|
| Latch lever function | Yes
|
| Lock case depth | 19 mm
|
| Lock case height | 215 mm
|
| Lock case material | Steel galvanised
|
| Lock case widths | Backset + 15 mm
|
| Requirement according to DIN 18251-2 | Class 2
|
| Reversible latch bolt | Yes, delivered as DIN left
|
| Suitable striking plates | 9516
|
| Usage | Tubular frame doors made of aluminium and steel
|
| Series | 0453
|
